MODELS: WS-48315 / WS-55315 / WS-65315
Cursor Coordinates
Specific intersections in the Crosshatch are assigned vertical and horizontal coordinates.
These are shown in the preceeding diagram. The Cursor can only be moved to those positions that
have coordinates assigned. If the Cursor is at coordinates outside the screen area, the Cursor will not be
visible. Use the ADJUST buttons to move the Cursor to an intersection on the screen.
Display
The on-screen display changes in the Fine mode, as shown below.
The display shows the vertical and horizontal data for the current
Cursor Position, and the horizontal and vertical coordinates for
that position.
F. Saving Data and Exiting the Convergence Mode
Press MENU twice to exit the Convergence mode, data is automatically saved.
Note: If power is interrupted, or the “CANCEL” button is presssed prior to properly exiting the Convergence
Mode, changes in adjustment data will not be saved. The data is restored to the last saved previous
values.
SD
Fine RED
13
H1
V3
-32
Horiz. H Coord. V Coord. Vert.
Data Data
ADJUSTMENT ITEMS LIST
Video Chroma Function
Item#
Abbrev.
Description
Range
480i
480p
1080i
Adjustment
1 SCT Picture Gain control 0~63 42 42 42 Sub Contrast
2 SBRT Sub Brightness 0~63 20 20 20 Black Level
3 SCON Sub Contrast 0~15 7 7 7 Preset
4 RDRH R Drive (H temp) 0~63 31 31 31 White Balance
5 GDRH G Drive (H temp) 0~63 41 41 41 Preset
6 BDRH B Drive (H temp) 0~63 31 31 31 White Balance
7 CTRH R Cutoff (H temp) 0~63 31 31 31 "
8 CTGH G Cutoff (H temp) 0~63 31 31 31 Preset
9 CTBH B Cutoff (H temp) 0~63 31 31 31 White Balance
10 RDRL R Drive (L temp) 0~63 31 31 31 "
11 GDRL G Drive (L temp) 0~63 41 41 41 Preset
12 BDRL B Drive (L temp) 0~63 31 31 31 White Balance
13 CTRL R Cutoff (L temp) 0~63 31 31 31 "
14 CTGL G Cutoff (L temp) 0~63 31 31 31 Preset
15 CTBL B Cutoff (L temp) 0~63 31 31 31 White Balance
16 GMMA RGB Gamma Correction 0~3 2 2 2 Preset
17 GAML Gamma Differential Corr. Switch 0~1 0 0 0 "
18 BRT Brightness 0~63 31 31 31 "
19 COL Color 0~63 38 34 33 White Balance
20 TINT Tint 0~63 29** 30 29 Preset
21 SHRP Sharpness 0~63 31 31 31 "
22 CBOF Cb DC Offset 0~63 31 31 31 "
23 CROF Cr DC Offset 0~63 31 31 31 "
31 VMLE VM Output Level 0~3 1 1 2 "
40 AGIW White output aging mode switch 0~1 0 0 0 "
55
ABLT
Threshold Adjust for ABL input
0~15
4*
4*
4*
"
* For models WS-65315 set data to 0
**For models WS-48315 set #20 TINT data to 29
For models WS-55315 set #20 TINT to 28
For models WS-65315 t #20 TINT data to 30
