Mitsubishi WS-48315 User Manual

MODELS: WS-48315 / WS-55315 / WS-65315
Page 36
Purpose:
Measuring
Instrument
Test Point
Measuring
Range
Input Signal
Ext. Trigger
Input Terminal
Symptom:
-----
------
------
-----
Video & DTV Inputs
To preset data controlling raster geometry
Raster distortion.
Note: This procedure is usually only necessary if an E2PROM is replaced in the TV
Control or Convergence circuits.
Procedure
In the Circuit Adjustment and Coarse Convergence Modes pre-set the data to the
values given in the Tables below.
[Conv/Defl]
13. Geometry Preset
NTSC & HD
Deflection Jungle
Menu-0-3-5-7
# Abbrev.
Item
Abbr.
NTSC
HD
NTSC
HD
NTSC
HD
1 HWID 30 29 23 22 30 28
2 HKEY 24 25 24 25 24 25
7 VHGT 18 16 14 13 33 31
8 VLIN 5 5 5 5 7 7
9 VSCN 0 0 0 0 0 0
18 VPOS 31 31 31 31 31 31
36
PINA
10
8
10
8
10
8
WS-65315WS-48315 WS-55315
Coarse Conv. Green
(Menu-0-3-5-9-5)
# Abbrev.
SD
HD
SD
HD
SD
HD
1
HSTA
0
0
0
0
0
0
2 VSTA 0 0 0 0 0 0
3 SKEW 0 0 0 0 0 0
4 TILT 0 0 0 0 0 0
5 HWID 20 20 20 20 20 20
6 HLIN 0 0 0 0 0 0
7 SPCC 0 0 0 0 0 0
8 HKEY 23 20 15 10 0 0
9 TBPC -180 -160 -190 -165 -200 -175
10 VKEY 0 0 0 0 0 0
11 VWID 30 20 30 20 30 20
12
VLIN
0
0
0
0
0
0
WS-55315WS-48315 WS-65315
Coarse Conv. Red Menu-0-3-5-9-5
# Abbrev
SD HD SD HD SD HD
1 HSTA 50 50 50 50 50 50
2 VSTA 0 0 0 0 0 0
3 SKEW 5 5 5 5 0 0
4 TILT 0 0 0 0 0 0
5 HLIN -220 -200 -215 -195 -170 -150
6 HWID 0 0 0 0 10 10
7 VKEY -90 -90 -75 -75 -90 -75
8 VWID 0 0 0 0 0 10
9 VLIN 0 0 0 0 0 0
10 TBPC 20 20 20 20 20 20
11 SDBW 30 30 30 30 30 30
WS-48315 WS-55315 WS-65315
Coarse Conv. Blue Menu-0-3-5-9-5
# Abbrev
SD HD SD HD SD HD
1 HSTA -50 -50 -50 -50 -50 -50
2 VSTA 0 0 0 0 0 0
3 SKEW 0 -5 0 -5 0 0
4 TILT 0 0 0 0 0 0
5 HLIN 220 200 220 205 175 160
6 HWID 0 0 0 0 10 10
7 VKEY 90 90 90 70 80 75
8 VWID 0 0 0 0 0 0
9 VLIN 0 0 0 0 0 0
10 TBPC 0 0 0 0 -20 0
11 SDBW -30 -30 -30 -30 -30 -30
WS-48315 WS-65315WS-55315
