MODELS: WS-48315 / WS-55315 / WS-65315
Page 27
CONVERGENCE MODE ITEMS
CONV MISC. MENU-0-3-5-9-6
Item# Abbrev. Description Range SD HD
1 HVOL HV Adjust 0~352 150 150
2 VCNT V-saw amplitude 0~127 29 29
3 VSTR V-saw start timer 0~127 0 10
4 VOFS V-saw offset 0~127 10 8
5 STLN Start line 0~127 38 26
6 FPHS Fine phase 0~352 303 294
7 CPHS Coarse phase 0~31 15 15
8 HOFS H-saw offset 0~127 22 22
9 DPHS DF coarse horiz phase 0~31 1 1
10 DOFS DF offset 0~127 34 34
11 TPHS Test Pattern phase 0~352 43 39
12 TPVD Test Pattern Vert. Position 0~127 23 39
13 ODEV Odd/Even detection 0~352 24 42
14 HRTC H-saw retrace 0~3 1 1
15 DRTC DF retrace 0~3 1 1
16 DAC External DAC selection 0~1 1 1
17 EPWP EEPROM write protection 0~1 0 0
Data
Deflection Jungle
Item Abbrev. Description HD NTSC HD NTSC HD NTSC HD
1 HWID Width 29 30 29 23 22 30 28
2 HKEY Horiz. Keystone 25 24 25 24 25 24 25
7 VHGT Height 16 18 16 14 13 33 31
8 VLIN Vert. Linearity 5 5 5 5 5 7 7
9 VSCN Vert. S Corr. 0 0 0 0 0 0 0
18 VPOS Vert. Position 31 31 31 31 31 31 31
36 PINA Pincushion Comp. 8 10 8 10 8 10 8
WS-65315WS-48315 WS-55315
474 OFFT MLINK picture position 31
39 SCNT Main Y-Out 0~31 16
Data
39 SCNT Main Y-Out 0~31 16
Data
