Mitsubishi WS-48315 User Manual

Page 28
MODELS: WS-48315 / WS-55315 / WS-65315
DF MENU-0-3-5-9-5
Item Abbr.
SD Data
HD Data
SD Data
HD Data
0 DFH -220 -220 -280 -250
1 DFV -100 -100 -110 -95
WS-48315 / WS-55315 WS-65315
COARSE CONV GREEN MENU 0-3-5-9-5
# Abbrev Description WS-55315 WS-65315
SD HD SD HD SD HD
1 HSTA Horiz. Position 0 0 0 0 0 0
2 VSTA Vert. Position 0 0 0 0 0 0
3 SKEW Skew (Y axis) 0 0 0 0 0 0
4 TILT Tilt (X axis) 0 0 0 0 0 0
5 HWID Width 20 20 20 20 20 20
6 HLIN Horiz. Linearity 0 0 0 0 0 0
7 SPCC Side PC Corr. 0 0 0 0 0 0
8 HKEY Horiz. Keystone 23 20 15 10 0 0
9 TBPC Top/Bottom PC -180 -160 -190 -165 -200 -175
10 VKEY Vert. Keystone 0 0 0 0 0 0
11 VWID Height 30 20 30 20 30 20
12 VLIN Vert. Linearity 0 0 0 0 0 0
COARSE CONV RED MENU 0-3-5-9-5
# Abbrev Description WS-55315 WS-65315
SD HD SD HD SD HD
1 HSTA Horiz. Position 50 50 50 50 50 50
2 VSTA Vert. Position 0 0 0 0 0 0
3 SKEW Skew (Y axis) 0 0 0 0 0 0
4 TILT Tilt (X axis) 0 0 0 0 0 0
5 HLIN Horiz. Linearity -220 -200 -215 -195 -170 -150
6 HWID Width 0 0 0 0 10 10
7 VKEY Vert. Keystone -90 -90 -75 -75 -90 -75
8 VWID Height 0 0 0 0 0 10
9 VLIN Vert. Linearity 0 0 0 0 0 0
10 TBPC Top/Bottom PC 20 20 20 20 20 20
11 SDBW Side Bow 30 30 30 30 30 30
COARSE CONV BLUE MENU 0-3-5-9-5
# Abbrev Description WS-55315 WS-65315
SD HD SD HD SD HD
1 HSTA Horiz. Position -50 -50 -50 -50 -50 -50
2 VSTA Vert. Position 0 0 0 0 0 0
3 SKEW Skew (Y axis) 0 0 0 -5 0 0
4 TILT Tilt (X axis) 0 0 0 0 0 0
5 HLIN Horiz. Linearity 220 200 220 205 175 160
6 HWID Width 0 -15 0 0 10 10
7 VKEY Vert. Keystone 90 90 90 70 80 75
8 VWID Height 0 0 0 0 0 0
9 VLIN Vert. Linearity 0 0 0 0 0 0
10 TBPC Top/Bottom PC -20 0 0 0 -20 0
11 SDBW Side Bow -30 -30 -30 -30 -30 -30
WS-48315
WS-48315
WS-48315
