Ref # Part # Part Name & Description [#]
Page 48
MODELS: WS-48315 / WS-55315 / WS-65315
Model Legend: (a) WS-48315, (b) WS-55315, (c) WS-65315
Ref # Part # Part Name & Description [#]
L9C51 321C141070 COIL-RF - 22MH-K
L9C52 351P244010 COIL-CHOKE - CD-C-1010-101
L9C53 321C141070 COIL-RF - 22MH-K
L9D00 351P243010 FILTER-LINE - CD-N-2637F-152
L9D01 351P243010 FILTER-LINE - CD-N-2637F-152
L9D02 351P223010 FILTER-LINE - SLF15N0601
LC2J40 409P777020 EMI-F-CHIP - BLM21A05
LC2J41 409P777020 EMI-F-CHIP - BLM21A05
LC2J42 409P777020 EMI-F-CHIP - BLM21A05
LC2J43 409P777020 EMI-F-CHIP - BLM21A05
LC3J41 409P777020 EMI-F-CHIP - BLM21A05
LC7CBA 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7CCA409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7CDA409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7D02 409P875090 EMI-F-CHIP - ELKE103FA
LC7D05 409P875090 EMI-F-CHIP - ELKE103FA
LC7D10 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7D11 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7D12 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7D13 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7D14 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7E10 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7E11 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7E12 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7E13 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7E14 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G01 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G02 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G03 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G04 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G05 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G06 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G07 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G08 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G09 409P875090 EMI-F-CHIP - ELKE103FA
LC7G10 409P875090 EMI-F-CHIP - ELKE103FA
LC7G11 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G12 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G13 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G14 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G15 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G16 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
LC7G17 409P876020 EMI-F-CHIP - CNF20C470S/CKD510JB1H470S
TRANSFORMERS
T5A31 349P221010 TRANS-HORIZ
T5A32 336P040010 TRANS-HORIZ-DRIVE
T5A51 334P281010 TRANS-FLYBACK
T9A20 350P806010 TRANS-PWR -
ETS19AB1R5BG
T9A50 350P807010 TRANS-PWR -
ETS42AD485NC
VARIABLE RESISTORS
129P070010 VR-FOCUS:MT010315-157
RV9D00 65P100020 VAR - ERZV10D271CS
RESISTORS
CHIP Type Resistors (Listed by Value)
Part No. Value part No. Value
103P509050 1/16W 0OHM 103P493020 1/16W 2K-F
103P508040 1/16W 2.2-J 103P493030 1/16W 2.2K-F
103P500050 1/16W 22-J 103P502090 1/16W 2.2K-J
103P500070 1/16W 33-J 103P493030 1/16W 2.2K-F
103P500080 1/16W 39-J 103P502090 1/16W 2.2K-J
103P500090 1/16W 47-J 103P493050 1/16W 2.7K-F
103P501000 1/16W 56-J 103P503000 1/16W 2.7K-J
103P501010 1/16W 68-J 103P493050 1/16W 2.7K-F
103P794060 1/16W 75-F 103P503000 1/16W 2.7K-J
103P509090 1/16W 75-J 103P503010 1/16W 3.3K-J
103P501020 1/16W 82-J 103P493090 1/16W 3.9K-F
103P501030 1/16W 100-J 103P503020 1/16W 3.9K-J
103P401030 1/10W 100-J 103P493060 1/16W 3K-F
103P501040 1/16W 120-J 103P494010 1/16W 4.7K-F
103P401050 1/10W 150-J 103P503030 1/16W 4.7K-J
103P490050 1/16W 150-F 103P494020 1/16W 5.1K-F
103P501050 1/16W 150-J 103P503040 1/16W 5.6K-J
103P490070 1/16W 180-F 103P494050 1/16W 6.8K-F
103P501060 1/16W 180-J 103P503050 1/16W 6.8K-J
103P501070 1/16W 220-J 103P503060 1/16W 8.2K-J
103P491000 1/16W 240-F 103P494090 1/16W 10K-F
103P501080 1/16W 270-J 103P503070 1/16W 10K-J
103P401080 1/10W 270-J 103P503080 1/16W 12K-J
103P491020 1/16W 300-F 103P503080 1/16W 12K-J
103P501090 1/16W 330-J 103P503090 1/16W 15K-J
103P491040 1/16W 360-F 103P504000 1/16W 18K-J
103P491050 1/16W 390-F 103P504010 1/16W 22K-J
103P502000 1/16W 390-J 103P504020 1/16W 27K-J
103P502010 1/16W 470-J 103P496000 1/16W 30K-F
103P491090 1/16W 560-F 103P504030 1/16W 33K-J
103P502020 1/16W 560-J 103P504040 1/16W 39K-J
103P492000 1/16W 620-F 103P504050 1/16W 47K-J
103P492010 1/16W 680-F 103P504060 1/16W 56K-J
103P502030 1/16W 680-J 103P496080 1/16W 62K-F
103P492030 1/16W 820-F 103P496090 1/16W 68K-F
103P502040 1/16W 820-J 103P504070 1/16W 68K-J
103P492050 1/16W 1K-F 103P504080 1/16W 82K-J
103P502050 1/16W 1K-J 103P504090 1/16W 100K-J
103P492060 1/16W 1.1K-F 103P505000 1/16W 120K-J
103P502060 1/16W 1.2K-J 103P505090 1/16W 680K-J
103P492090 1/16W 1.5K-F 103P506000 1/16W 820K-J
103P502070 1/16W 1.5K-J 103P506010 1/16W 1M-J
103P402070 1/8W 1.5K-J 103P506070 1/16W 3.3M-J
103P502080 1/16W 1.8K-J
RESISTORS
Conventional Resistors (By Ref #)
Ref # Part # Part Name & Description [#]
R2J21 109D151050 R-CARBON - 1/4W 75-J
R2J31 109D151050 R-CARBON - 1/4W 75-J
R3E02 103P712080 R-CARBON - 1/4W 1.8K-J
R3E04 103P712080 R-CARBON - 1/4W 1.8K-J
R3E05 103P714060 R-CARBON - 1/4W 56K-J
R3E06 103P713080 R-CARBON - 1/4W 12K-J
R3E09 109D151010 R-CARBON - 1/4W 2.2-J
