Ref # Part # Part Name & Description [#]
Page 52
MODELS: WS-48315 / WS-55315 / WS-65315
Model Legend: (a) WS-48315, (b) WS-55315, (c) WS-65315
Ref # Part # Part Name & Description [#]
CAPACITORS & TRIMMERS
CHIP Type Capacitors (Listed by Value)
Part No. Value Part No. Value
154P350040 SL50V 2P-C 141P141010 B50V 1500P-K
154P340040 50V 3P-C 141P141030 B50V 2200P-K
154P341010 CH50V 10P-C 141P141070 B50V 4700P-K
154P351020 SL50V 10P-J 141P143080 F50V 0.01M-Z
154P341030 CH50V 12P-J 141P142010 B50V 0.01M-K
154P341050 CH50V 15P-J 141P143010 B25V 0.068M-K
154P341090 CH50V 22P-J 141P143020 B16V 0.082M-K
154P342030 CH50V 33P-J 141P134090 F50V 0.1M-Z
154P342070 CH50V 47P-J 141P144020 F25V 0.1M-Z
154P342090 CH50V 56P-J 141P143030 B16V 0.1M-K
154P353000 SL50V 56P-J 141P146040 B10V 0.22M-K
154P343030 CH50V 82P-J 141P138080 B25V 0.33M-K
154P343050 CH50V 100P-J 141P146080 B10V 0.47M-K
154P343070 CH50V 120P-J 141P139090 B16V 0.47M-K
154P343090 CH50V 150P-J 181P526010 50V 1M-M
141P140010 B50V 220P-K 141P144060 F16V 1M-Z
154P344030 CH50V 220P-J 141P147020 B10V/6.3V 1M-K
154P344050 CH50V 270P-J 181P526020 50V 2.2M-M
141P140050 B50V 470P-K 181P532030 16V 10M-M
154P345030 CH25V 560P-J 181P530030 6.3V 47M-M
154P345070 CH25V 820P-J 181P520030 6.3V 47M-M
141P140090 B50V 1000P-K 181P522060 6V 47M-M
154P345090 CH25V 1000P-J 181P520040 6.3V 100M-M
Capcitors by Reference #
Ref # Part # Part Name & Description [#]
C1A13 181P352040 C-ELEC - 16V 100M-M
C1A21 181P352040 C-ELEC - 16V 100M-M
C1A24 181P352040 C-ELEC - 16V 100M-M
C1A26 172P262010 C-M-POLY - 50V 0.047M-J
C1B13 181P355090 C-ELEC - 50V 100M-M
C1B21 181P352040 C-ELEC - 16V 100M-M
C1B24 181P352040 C-ELEC - 16V 100M-M
C1B26 172P262010 C-M-POLY - 50V 0.047M-J
C2AGC 155P239040 C-CER - CH50V 100P-J
C2AGD 142P024060 C-CER - BF50V 0.1M-Z
C2AJB 142P024060 C-CER - BF50V 0.1M-Z
C2AJD 155P239040 C-CER - CH50V 100P-J
C2AKC 181P352040 C-ELEC - 16V 100M-M
C2AKD 155P239040 C-CER - CH50V 100P-J
C2ANC 142P024060 C-CER - BF50V 0.1M-Z
C2AND 155P239040 C-CER - CH50V 100P-J
C2APC 181P352040 C-ELEC - 16V 100M-M
C2APD 155P239040 C-CER - CH50V 100P-J
C2ARC 142P024060 C-CER - BF50V 0.1M-Z
C2ARD 155P239040 C-CER - CH50V 100P-J
C2ATC 142P024060 C-CER - BF50V 0.1M-Z
C2ATD 155P239040 C-CER - CH50V 100P-J
C2AYC 142P024060 C-CER - BF50V 0.1M-Z
C2AYD 155P239040 C-CER - CH50V 100P-J
C2AZC 142P024060 C-CER - BF50V 0.1M-Z
C2AZE 181P355050 C-ELEC - 50V 10M-M
C2AZF 155P239040 C-CER - CH50V 100P-J
C2K01 181P355050 C-ELEC - 50V 10M-M
C2K03 181P355050 C-ELEC - 50V 10M-M
C2K08 181P355050 C-ELEC - 50V 10M-M
C2K10 181P355050 C-ELEC - 50V 10M-M
C2K15 181P355050 C-ELEC - 50V 10M-M
C2K17 181P355050 C-ELEC - 50V 10M-M
C2K18 181P351060 C-ELEC - 10V 330M-M
C2K22 181P355050 C-ELEC - 50V 10M-M
C2K27 181P355050 C-ELEC - 50V 10M-M
C2K43 181P352030 C-ELEC - 16V 47M-M
C2K48 181P352030 C-ELEC - 16V 47M-M
C2K50 181P355050 C-ELEC - 50V 10M-M
C2K63 181P355050 C-ELEC - 50V 10M-M
C2K71 181P352030 C-ELEC - 16V 47M-M
C2K75 181P352030 C-ELEC - 16V 47M-M
C2L29 181P352030 C-ELEC - 16V 47M-M
C2L52 181P352030 C-ELEC - 16V 47M-M
C2M28 181P351080 C-ELEC - 10V 1000M-M
C2M29 181P351080 C-ELEC - 10V 1000M-M
C2M31 181P352030 C-ELEC - 16V 47M-M
C2M34 181P352030 C-ELEC - 16V 47M-M
C2M36 181P352030 C-ELEC - 16V 47M-M
C2M38 181P352030 C-ELEC - 16V 47M-M
C2M43 181P352030 C-ELEC - 16V 47M-M
C2M44 181P352030 C-ELEC - 16V 47M-M
C2M54 181P355050 C-ELEC - 50V 10M-M
C2M64 181P352030 C-ELEC - 16V 47M-M
C2M80 181P352030 C-ELEC - 16V 47M-M
C2M88 181P355010 C-ELEC - 50V 1M-M
C2M89 181P352030 C-ELEC - 16V 47M-M
C2M98 181P355050 C-ELEC - 50V 10M-M
C2MA4 181P352030 C-ELEC - 16V 47M-M
C2MA6 181P352030 C-ELEC - 16V 47M-M
C2MA9 181P352030 C-ELEC - 16V 47M-M
C2MC4 181P352030 C-ELEC - 16V 47M-M
C2MC8 181P352040 C-ELEC - 16V 100M-M
C2MD6 181P352040 C-ELEC - 16V 100M-M
C2MD7 181P352040 C-ELEC - 16V 100M-M
C2N03 181P352070 C-ELEC - 16V 470M-M
C2N27 181P350060 C-ELEC - 3V 1000M-M
C2NA6 181P355050 C-ELEC - 50V 10M-M
C2NC5 181P355050 C-ELEC - 50V 10M-M
C2P01 181P352070 C-ELEC - 16V 470M-M
C2P26 181P350060 C-ELEC - 3V 1000M-M
C2P32 181P352030 C-ELEC - 16V 47M-M
C2P42 181P352030 C-ELEC - 16V 47M-M
C2R29 181P352030 C-ELEC - 16V 47M-M
C2V14 181P352040 C-ELEC - 16V 100M-M
C2V17 181P355040 C-ELEC - 50V 4.7M-M
C2V19 181P352040 C-ELEC - 16V 100M-M
C2V29 181P352040 C-ELEC - 16V 100M-M
C2V30 181P118010 C-ELEC - 50V 0.68M-M
C2V32 181P355000 C-ELEC - 50V 0.47M-M
C2V48 172P166030 C-TF - 50V 0.1M-J
C2V49 172P166030 C-TF - 50V 0.1M-J
C2V55 181P352040 C-ELEC - 16V 100M-M
C2V57 181P355060 C-ELEC - 50V 22M-M
C2V61 181P352040 C-ELEC - 16V 100M-M
C2W02 181P352080 C-ELEC - 16V 1000M-M
C2W05 181P352030 C-ELEC - 16V 47M-M
C2W09 181P352030 C-ELEC - 16V 47M-M
C2W14 181P352030 C-ELEC - 16V 47M-M
