Miyachi MG3D - Connector X60 and X61 (Canopen)

Operating Instructions MG3 Digital
Commissioning
76609409EN-BA-MG3D-V1_6.docx 18/82 2010-08-02
3.1.2.6 Connector X60 and X61 (CANopen)
Connection with standard RS232-extension cable (1:1)
Pin Name Function
1 Free
2 CAN_L Low-level
3 CAN_GND Ground
4 Free
5 CAN_SHLD Circuit shield
6 Free
7 CAN_H High-level
8
9
CAN-Baud rates 1MB/s
800 kB/s
500 kB/s
250 kB/s
125 kB/s
50 kB/s
20 kB/s
10 kB/s
