Operating Instructions MG3 Digital
Integration in Automated Installations
76609409EN-BA-MG3D-V1_6.docx 68/82 2010-08-02
6.2 Flow Chart Channel 1 and Channel 2 Parallel
Dia2-MG3
high
high
high
high
high
high
high
high
high
high
low
low
low
low
low
low
low
low
low
low
high
high
low
low
external programm
selection input
accept outputs
delete accept
set reject
input
set accept
delete reject
input
new measuring sequenceprogramm takeover
after evaluation
external
programm
changeover
Reject 2 Output
Reject 1 Output
Outputs
limit values
pre-warn
value
Current 1 Output
Current 2 Output
Ready Output
Current 1
Current 2
measuring delay
adjusted measuring time channel1
adjusted measuring time channnel 2
no new measuring possible
Both measuring times need to be set generously enough so that they overlap in a 2-
channel parallel measurement.
As soon as the current outputs become “low” (within measuring interval), evaluation of the
set outputs can commence.
New measurement can be only started after the ready signal is “high”.
