Operating Instructions MG3 Digital
How to …?
76609409EN-BA-MG3D-V1_6.docx 36/82 2010-08-02
Equivalencies of parameters
Differently from normal measure mode „coil“ several menu points in measure mode
„shunt“ are not active or are otherwise assigned.
Overview:
X = active menu point
- = inactive menu point
Menu item Channel 1 Channel 2 Adjustable values
Filter X welding position
voltage
X shunt voltage ON/OFF 0.1-25kHz
Measuring mode X - Coil/Shunt
Current profile - X Point/Seam (Option)
Trigger source - X Current/Force
trigger/
0 penetration
Trigger - X 0-100% of
measuring range end
value
I fall value X shunt current X X shunt voltage 10-95% from peak
value
Measuring time - X 1-2000(DC)/1-
5000(AC)ms
Measuring pause - X 0-2000 ms
Current type - X AC/DC
Current X shunt current - 2kA-500 kA
Voltage X welding position
voltage
X shunt voltage 0.5V-50 V
Sector signal X welding position
voltage
X shunt voltage 0 measuring time ms
