MKS 356 Micro-Ion Plus Series User Manual

Operation
Micro-Ion
®
Module Instruction Manual - 356007-GP 43
Installation Operation MaintenanceBefore You Begin
Figure 3-13 Data Timing and Response Delays
Table 3-9 Data Timing and Response Delay Limits
Timing Segment Time Limit
Time T
D
(time for host to switch from transmit to receive) 1.2 msec minimum
12.0 msec maximum
Time T
R
(data processing and response time)
Time T
P
(data processing time) See Table 3-11
Time D (time for module to switch from transmit to receive) 200 μsec minimum
1.0 msec maximum
Total response time
1
Baud
-------------
130×


Time
P
+
Time T
D
Time
R
Time D++
Table 3-10 Baud Rate and Data Response Time
Baud Rate Response Time
1200 baud 108 msec
2400 baud 54 msec
4800 baud 27 msec
9600 baud 13.5 msec
19200 baud (default) 6.75 msec
38400 baud 3.3 msec
