Working with Sensors
5.4.2 LASER SENSOR
Generally, the laser sensor is mounted on a pole or mast. See the practical example for
reference. It is important that the laser sensor is mounted tight and secured to the mast.
The mounting should be robust enough to guarantee that the sensor will not move while
the blade is being used.
Ensure that the laser transmitter is stable and the beam is within the laser sensors
upper and lower limits.
Refer to general sensor settings in section 5.1 for adjusting the laser sensor
parameters.
LASER SENSOR TYPES
R.ULS.CAN and R.ULS.MM.CAN
R.ULS.MM.CAN
R.ULS.CAN
Figure 5.4.2.1
