EXACTA
68
EV1
EV2
EV3
EVWP
EVP1
F1
F2
F3
F4
Water entry/vapour discharge valve
Air bleeding electrovalve
Air entry electrovalve
Water pump electrovalve
Vacuum pump electrovalve
Electronics fuse – T 1.6A/250V
Electrovalve fuse - T 1.6A/250V
Heating resistance fuse - T 10A/250V
Power transformer fuse - T
315mA/250V
He
SW
T1
T2
WP
VP1
Tc1
Ts1
Ts2
Heating resistance
Mains switch
Distilled water tank
Used water tank
Distilled water pump
Vacuum pump
Safety thermostat
Inner temperature probe
Outer temperature probe
