Mocom Exacta - Hydraulic Drawing

EXACTA
69
APPENDIXES
1 2
T2
R3
S1
1
2
He
H2O
CHAMBER
Tc1
Ts2
EV3
AIR
FA
FB
EV2
FV
SV
PP
Ts1
V1
WP
EV WP
FW
T1
R2
1
2
EV1
EVP1
1
2
VP1
H2O
H2O
R1
SINK
LEGEND
EV1
Electrovalve 24Vdc 2 ways
R2
Distilled water draining point
EV2
Electrovalve 24Vdc 2 ways
R3
Used water draining point
EV3
Electrovalve 24Vdc 2 ways
SINK
Vapour heatsink
EVP1
Pump electrovalve 220Vac 2 ways
S1
Air bleeding coil
EVWP
Water electrovalve 220Vac 2 ways
T1
Distilled water reservoir
FA
Air filter
T2
Used water reservoir
FB
Bacteriologic filter
Tc1
Safety thermostat
FV
Vapour filter
Ts1
Inner temperature probe
FW
Distilled water filter
Ts2
Outer temperature probe
HYDRAULIC DRAWING
