Modine Manufacturing MPR - Table 58.1 - Model Nomenclature - Main Unit

58 MCP15-500.7
MODEL NOMENCLATURE - MODEL MPR
(Continued on next page)
Table 58.1 - Model Nomenclature - Main Unit
Digits Indicates Description Value
Cabinet
B C D
1, 2, 3 Unit Type Commercial Packaged Ventilation Unit MPR ● ● ●
4, 5 Unit Nominal Cooling
7, 10, or 13 ton 07, 10, 13 ●
15 or 20 ton 15, 20 ● ●
26 ton 26 ●
30 ton 30 ● ●
40, 52, or 60 ton 40, 52, 60 ●
6 Cabinet Size Refer to Dimensions B, C, D ● ● ●
7 AirControlConguration
OA & RA Dampers
No Exhaust A ● ● ●
Energy Recovery Exhaust B ● ● ●
Power Exhaust C ● ● ●
OA Dampers (No RA) No Exhaust D ● ● ●
OA Dampers
(with Exhaust Opening)
Energy Recovery Exhaust E ● ● ●
Power Exhaust F ● ● ●
8 Evaporator Coil
High Capacity 4 Row, 14fpi
DX Coil
No E-Coat 1 ● ●
With E-Coat 2 ● ●
High Capacity 6 Row, 14fpi
DX Coil
No E-Coat 3 ●
With E-Coat 4 ●
9 Compressor Staging
Tandem Digital Scroll (Digital Modulating + On/Off) (10-30 ton units) A ● ●
Single Digital Scroll (Modulating Digital) (7 ton units only) B ●
Dual Tandem Digital Scroll [(Digital Modulating - On/Off) & (On/Off - On/Off)] D ●
10 Hot Gas Reheat
No Hot Gas Reheat 0 ● ● ●
Modulating Hot Gas Reheat 1 ● ● ●
Modulating Hot Gas Reheat with E-Coat 2 ● ● ●
11 Condensor Arrangement
VFD Head Pressure Control
Microchannel Coils A ● ●
Microchannel Coils with E-Coat (UV) B ● ●
Modulating EC Motor Head
Pressure Control
Microchannel Coils E ●
Microchannel Coils with E-Coat (UV) F ●
12 SupplyBlowerConguration
Wheel Size
(inches)
Belt Drive
j
Direct Drive
ANPA
k ANPL k ANPA k ANPL k
11 - 1 - K ●
12 - - 4 L ●
14 - - 7 M ●
16 2 - 8 N ● ●
20 3 - A Q ● ●
25 5 - C S ● ●
28 6 - - - ●
16 Dual - - E U ●
25 Dual - - J Y ●
13
Supply Blower Motor HP
l
1 HP C or Q ● ● ●
1-1/2 HP D or R ● ● ●
2 HP E or S ● ● ●
3 HP F or T ● ● ●
5 HP G or U ● ● ●
7-1/2 HP H or V ● ● ●
10 HP J or W ● ● ●
15 HP K or X ● ● ●
20 HP L or Y ●
14 Blower Motor Type
Supply Fan Motor Exhaust Fan Motor
ODP 1800 RPM 1800 RPM or N/A 1 ● ● ●
ODP 3600 RPM 1800 RPM or N/A A ● ● ●
ODP 1200 RPM 1800 RPM or N/A G ● ● ●
TE 1800 RPM 1800 RPM or N/A 2 ● ● ●
TE 3600 RPM 1800 RPM or N/A B ● ● ●
TE 1200 RPM 1800 RPM or N/A H ● ● ●
15 Unit Supply Voltage
208V/3ph 4 ● ● ●
230V/3ph 5 ● ● ●
460V/3ph 6 ● ● ●
575V/3ph (not available on 52/60 ton D-Cabinet) 7 ● ● ●
16 Power Options
Deadfront Disconnect Convenience Outlet
None
None N ● ●
Power by Others Z ● ●
60A
None D ● ●
Unit Powered E ● ●
Power by Others F ● ●
100A
None G ● ● ●
Unit Powered H ● ● ●
Power by Others J ● ● ●
200A
None K ● ● ●
Unit Powered L ● ● ●
Power by Others M ● ● ●
400A
None P ● ● ●
Unit Powered Q ● ● ●
Power by Others R ● ● ●
600A
None S ●
Unit Powered T ●
Power by Others U ●
