Modine Manufacturing MPR - D-Cabinet Size Unit

42 MCP15-500.7
DIMENSIONS - D-CABINET SIZE UNIT
180.00
(BASE)
EVAPORATOR &
HOT GAS REHEAT COIL
SERVICE ACCESS PANEL
1-1/2" NPT EVAP
COIL DRAIN
PAN PIPE
CONNECTION
137.16
SUPPLY AIR
BLOWER DOOR
FILTER & DAMPERS
ACCESS DOOR
180.63 40.36
29.45
CONDENSING
SECTION
COMPRESSOR
COMPARTMENT
ACCESS DOOR
HIGH VOLT CONTROLS
COMPARTMENT
ACCESS DOOR
GAS/ELECTRIC
HEAT (OPTION)
COMPARTMENT
ACCESS DOORS
97.60
104.25
(LUGS)
GAS SERVICE
ENTRANCE
GAS SERVICE
ENTRANCE
(4) 1.00" LIFTING LUGS
(EACH CORNER OF UNIT)
(4) TIE DOWN POINTS
(EACH CORNER OF UNIT)
APPROXIMATE AREA
FOR SIDE ELECTRIC
SERVICE ENTRANCE
(refer to Warning label
on unit for exact location)
LOW VOLT CONTROLS
COMPARTMENT
ACCESS DOOR
EVAPORATOR &
HOT GAS REHEAT COIL
SERVICE ACCESS PANEL
100.51
100.75
(BASE)
CONDENSING SECTION FAN QUANTITY:
(4) FANS FOR 30 AND 40 TON UNIT
(6) FANS FOR 52 AND 60 TON UNITS
103.07
ACCESSORY RAINHOOD
AND BIRDSCREEN
(FIELD INSTALLED ACCESSORY)
43.56
(LUGS)
120.94
(LUGS)
Figure 42.1 - Unit Dimensions (inches)
