59MCP15-500.7
MODEL NOMENCLATURE - MODEL MPR - CONTINUED
j Supply fans with belt drive are no longer offered and are shown for historical purposes. All units shipped after December, 2017 are direct drive supply fans.
k ANPA are airfoil fans, ANPL are non-airfoil fans.
l C through L include a Motor Starter, Q through Y include a Variable Frequency Drive (VFD).
m MPR C-Cabinet units that interface to energy recovery exhaust will always be "N". The Wheel Diameter, Exhaust Blower Configuration, Exhaust Blower
Motor HP, and Energy Wheel Preheat is called out in the ERM model nomenclature, when applicable, on C-Cabinet sized units. All D-Cabinet units are “N”.
Table 59.1 - Model Nomenclature - Main Unit (Continued from previous page)
Digits Indicates Description Value
Cabinet
B C D
17 Heating Section Type
None 0 ● ● ●
Electric 1 ● ● ●
Natural Gas 2 ● ● ●
Natural Gas with 20kW (nominal) Aux/Supplemental Electric Heat 3 ● ●
Natural Gas with 40kW (nominal) Aux/Supplemental Electric Heat 3 ●
Hot Water (C-Cabinet Only) 4 ●
18 Nominal Heat Capacity
No Heating N ● ● ●
20kW Electric - (derate for 208V/3ph)
A
● ●
40kW Electric - (derate for 208V/3ph) ●
40kW Electric - (derate for 208V/3ph)
B
● ●
80kW Electric - (derate for 208V/3ph) ●
60kW Electric - (derate for 208V/3ph)
C
● ●
120kW Electric - (derate for 208V/3ph) ●
80kW Electric - (derate for 208V/3ph)
D
● ●
160kW Electric - (derate for 208V/3ph) ●
100kW Electric - (derate for 208V/3ph)
E
● ●
200kW Electric - (derate for 208V/3ph) ●
150 MBH Gas - 80% 1 x 150 F ●
200 MBH Gas - 80% 1 x 200 G ●
250 MBH Gas - 80% 1 x 250 H ●
300 MBH Gas - 80% 1 x 300 (B), 2 x 150 (C) J ● ●
400 MBH Gas - 80% 1 x 400 (B), 2 x 200 (C, D) K ● ● ●
500 MBH Gas - 80% 2 x 250 L ● ●
600 MBH Gas - 80% 2 x 300 M ● ●
620 MBH Gas - 90% 2 x 310 P ●
800 MBH Gas - 80% 2 x 400 Q ●
175 MBH Gas - 94% 1 x 175 R ●
225 MBH Gas - 94% 1 x 225 S ●
310 MBH Gas - 94% 1 x 310 T ●
350 MBH Gas - 90% 2 x 175 U ●
450 MBH Gas - 90% 2 x 225 V ● ●
900 MBH Gas - 80% 2 x 200 + 2 x 250 (stacked) 1 ●
1000 MBH Gas - 80% 4 x 250 (stacked) 2 ●
1200 MBH Gas - 80% 4 x 300 (stacked) 3 ●
1400 MBH Gas - 80% 2 x 300 + 2 x 400 (stacked) 4 ●
1600 MBH Gas - 80% 4 x 400 (stacked) 5 ●
850 MBH Gas - 86% 2 x 200 + 2 x 225 (stacked) 6 ●
950 MBH Gas - 86% 2 x 250 + 2 x 225 (stacked) 7 ●
1220 MBH Gas - 86% 2 x 300 + 2 x 310 (stacked) 8 ●
1420 MBH Gas - 86% 2 x 400 + 2 x 310 (stacked) 9 ●
Hot Water Coil (only available on C-Cabinet) W ●
19 Temperature Rise
Not Applicable N ● ● ●
High Air Temp Rise (70°F to 100°F) H ● ● ●
Low Air Temp Rise (30°F to under 75°F) L ● ● ●
20 Heat Control
No Heating N ● ● ●
Modulating D ● ● ●
21
Nominal Wheel Diameter
m
None (or Not Applicable for C- and D-Cabinet) N ● ● ●
28” A ●
36” B ●
48” C ●
22
Exhaust Blower
Conguration
m
None (or Not Applicable for C- and D-Cabinet) N ● ● ●
11” Backward Inclined Plenum Fan 1 ●
16” Backward Inclined Airfoil Plenum Fan 2 ●
20” Backward Inclined Airfoil Plenum Fan 3 ●
23
Exhaust Blower Motor HP
lm
None (or Not Applicable for C-Cabinet) N ● ● ●
1 HP C or Q ●
1-1/2 HP D or R ●
2 HP E or S ●
3 HP F or T ●
5 HP G or U ●
7-1/2 HP H or V ●
10 HP J or W ●
24
Energy Wheel Preheat
m
None (or Not Applicable for C- and D-Cabinet) N ● ● ●
20kW (nominal) Electric 2 ●
To Next Page
