03/05 AWB2724-1453G
Technical data
75
CANopen
Maximum data transmission rate bit/s Operating system version < 2.0: maximum 250000
Operating system version = 2.0: maximum 1000000
Electrical isolation Yes
Device profile To DS301V4
PDO type Asyn., cyc., acyc.
Connection Plug-in spring-loaded terminal block, 6-pole
Bus termination resistors External
Stations No.
Up to 126
Watchdog Yes
RTC (real-time clock) Yes
Supply voltage for the local inputs/outputs (24 V
Q
/0 V
Q
)
Input voltage V DC 24
Voltage range V DC 19.2 to 30, observe polarity
Electrical isolation
Between supply and CPU voltage Yes
Overvoltage protection Yes
Polarity protection Yes
Digital inputs
Input current per channel at rated voltage mA typ. 3.5
Power dissipation per channel
typ. 85 mW
Switching levels as per EN 61131-2
Limit values type “1” low < 5 V DC, high > 15 V DC
Input delay
Off r On ms typ. 0.1
On r Off ms typ. 0.1
Inputs No. 8
Channels with common reference potential No.
8
Status indicator
LED
Digital outputs
1
Power dissipation per channel
QX0.0 and QX0.5 W 0,08
Load circuits
QX0.0 and QX0.5 A 0,5
Output delay
Off r On typ. 0.1 ms
On r Off
typ. 0.1 ms
Channels No.
6
Channels with common reference potential No. 6
Status indicator LED
ON-time (duty cycle) % ED 100
Simultaneity factor g 1
1) Observe the limitations with use of the XC-CPU101 in an ABS enclosure, a table 1 on page 8.
XC-CPU101-C...K-8DI-6DO(-XV)
