RS232 interface in transparent
mode (COM 1/2/3)
03/05 AWB2724-1453G
76
XT-FIL-1 24 V DC filter
General
Standards and regulations IEC/EN 61131-2
EN 50178
Ambient temperature °C 0 to +55
Storage °C –25 to +70
Mounting position Horizontal/vertical
Relative humidity, no condensation (IEC/EN 60068-2-30) % 10 to 95
Air pressure (in operation) hPa 795 to 1080
Vibration resistance
10 to 57 Hz g0.075 mm
57 to 150 Hz g1.0 g
Mechanical shock resistance
15 g/11 ms
Shock resistance 500 g/o 50 mm g 25 g
Overvoltage category II
Pollution degree
2
Enclosure protection IP 20
Rated impulse voltage V 850
Interference emission EN 50081-2, Class A
Interference immunity EN 50082-2
Weight g 95
Dimensions (W x H x D) mm 35 x 90 x 30
Connecting terminals Screw terminal
Conductor cross-section
Screw terminals
Stranded with ferrule mm
2
0.2 to 2.5 (AWG22-12)
Solid core mm
2
0.2 to 2.5 (AWG22-12)
Power supply
Input voltage V DC 24
Permissible range V DC
20.4 to 28.8
Residual hum and ripple % F 5
Overvoltage protection Yes
Electrical isolation
Input voltage to PE Yes
Input voltage to output voltage No
Output voltage to PE Yes
Output voltage V DC 24
Output current A 2,2
