Specifications
EPM2000/EPM2000e Reference Guide
61
INTERNAL TRIGGER
• Adjustable 2% to 20%
RS-232 BAUD RATES
• 38400, 19200, 9600, 4800, 2400, and 1200
POWER REQUIREMENTS
• 90 to 264 VAC at frequencies between 50 Hz and 60 Hz
DIMENSIONS
• 30.48 cm x 27.31 cm x 11.43 cm (12" x 10.75" x 4.5")
WEIGHT
• 2.90 kg (6.38 lbs)
FIRMWARE REVISIONS
Every EPM2000 contains three programmed chips, one for each analog board and one for the digital
board. Knowing the firmware revisions of these chips is useful when calling Molectron Detector,
Inc. Press
to see the digital firmware revision.
Print that number here: __________________ (digital firmware revision)
Press
to see the analog firmware revision.
Print that number here: __________________ (analog firmware revision)
