Flow Chart 2: Window Tuning Mode
RS = Rotary Switch Position
LED Colour
RS = 0
MechTool
TM
Mode - Entry
Set RS to position 0 Green
Press and hold program button for a
minimum of 2 seconds.
Red
Release the program button when the
LED flashes Yellow.
Flashing Yellow
RS = 2
Window Tuning Mode
Set RS to position 2 Flashing Yellow
Press and release the program button. Yellow-Green
Set the rotary switch corresponding to
the window number to be tweaked.
i.e.
position 1 = window 1,
position F = window 16.
Press and release the program button. Yellow-Red
Select window Tweak
See Table 3
Press and release the program button. Flashing Yellow
RS = 0
MechTool
TM
Mode - Exit
Set RS to position 0 Flashing Yellow
Press and hold program button for a
minimum of 2 seconds.
Yellow-Green
Release the program button when the
LED = Yellow-Green.
Green
This programs the window tweaks into EEPROM.
See Note in section 10 Window Tuning
