4.3 Opto Test
This mode is used for checking whether the various opto electronic devices used in the
product are working correctly.
ON = opto blocked or not fitted.
Accept 1
⇒
DCE coin opto
Accept 2
⇒
DCE token opto
Accept 3
⇒
Sorter optos
Accept 4
⇒
Off
Accept 5
⇒
Off
Accept 6
⇒
Off
The test is interactive, so the optos can be blocked and unblocked with a small piece of card
to see if they are working correctly.
The only way to distinguish between a blocked opto – fault – and a missing opto is to
physically look for the optic.
Note: These tests are only useful if the relevant hardware is fitted, i.e. DCE chute and sorter.
4.4 Exit Diagnostics
To exit the diagnostic tests, remove the links and press the program button until the LED
turns Green.
0
V
0
V
Jumper
Jumper
