Flow Chart 8: Erase ALL Windows
RS = Rotary Switch Position
LED Colour
RS = 0
MechTool
TM
Mode - Entry
Set RS to position 0 Green
Press and hold program button for
a minimum of 2 seconds.
Red
Release the program button when
the LED flashes Yellow.
Flashing Yellow
RS = 8
Erase ALL Windows
Set RS to position 8. Flashing Yellow
Press and release the program
button.
Yellow-Green
Press and release the program
button within 1 sec of first press*.
Red to confirm window
deletion then changes to
Flashing Yellow.
RS = 0
MechTool
TM
Mode - Exit
Set RS to position 0 Flashing Yellow
Press and hold program button for
a minimum of 2 seconds.
Yellow-Green
Release the program button when
the LED = Yellow-Green.
Green
* Keep pressing twice – until the LED changes to RED = Windows Erased.
This clears ALL the windows in EEPROM, including window tweaks.
As a safeguard with this function, the program button must be pushed twice within 1 second to
ensure erasure of the coin windows.
Failure to do so will leave the coin windows intact.
