10. Window Tuning
The window offset applies to both the upper and lower window limits, e.g. if window offset = 1,
window is narrowed by 2 counts i.e. the upper window limit is reduced by 1, and the lower
window limit is increased by 1.
The rotary switch allows the following security window tweaks to be programmed.
Note:- It is still possible to access this function using MechTool
TM
and tweak the coin windows
even though Window Tweaks may have been disabled.
The tweak information is saved in the EEPROM memory and only comes into effect when the
coin tweak flag is enabled using MechTool
TM
,
Flow Chart 6: Flag Change Mode or
ccProgrammer.
10.1 Window adjustment table
Two flags in EEPROM control the tuning as shown in the table below.
Individual
Tuning
Secure
Tuning
SR5 Functional Operation
OFF* OFF* No coin window modification is possible.
OFF ON No coin window modification is possible.
ON OFF Individual window tweaks possible.
ON ON
Individual window tweaks possible, tweaks can only
narrow programmed window.
* Indicates factory default settings.
Table 2: Window Adjustment Table
The above can be set or cleared using MechTool
TM
to change the flag settings, see Flow
Chart 6: Flag Change Mode, Flags 6, 7, 8 and 9.
