Flow Chart 7: Reset Individual Coin Tweaks
RS = Rotary Switch Position
LED Colour
RS = 0
MechTool
TM
Mode - Entry
Set RS to position 0 Green
Press and hold program button
for a minimum of 2 seconds.
Red
Release the program button
when the LED flashes Yellow.
Flashing Yellow
RS = 7
Reset Individual Coin Tweaks
Set RS to position 7. Flashing Yellow
Press and release the program
button.
Red to confirm coin tweaks
reset then changes to
Flashing Yellow.
RS = 0
MechTool
TM
Mode - Exit
Set RS to position 0 Flashing Yellow
Press and hold program button
for a minimum of 2 seconds.
Yellow-Green
Release the program button
when the LED = Yellow-Green.
Green
This clears the tweaks in EEPROM for ALL coin windows.
