SR5 MechTool
TM
Manual TSP012.doc Issue 2.1 – June 2004
©Money Controls 2004. All rights reserved.
Page 4 of 24
2. Introduction
The SR5 now incorporates an advanced programming feature named “MechTool
TM
”, which
uses the program button, diagnostic pins and the rotary switch. The LED is used to guide the
user through the operations. It is assumed the SR5 is powered-up in parallel mode and all the
relevant internal Eeprom settings are set appropriately to perform the functions listed.
Note: MechTool
TM
ON, must be specified when ordering, otherwise the following features will
NOT be available.
2.1 Diagnostics
This feature enables certain self checks / tests to be made on the SR5, these include:-
2.2 Inhibit / Accept line and Inductive Noise Test
This mode can be used to check the inhibit and accept lines are working correctly. It will
also indicate the level of environmental noise detected by the sensors.
2.3 Solenoid and Inductive Sensor Flash Test
This mode checks the operation of the solenoids used in the SR5 and the status of the
sensor coils – whether they are functioning or not.
2.4 Opto Test
This mode checks the status of the opto’s used in the SR5 and the dual coin entry rundown.
2.5 MechTool
TM
MechTool
TM
has been added to the SR5 to enable the customer to change various features
and options, within the product, without the use of an external programmer. While this is a
powerful and useful feature, if used without caution, changes can be made which may affect
the operation of the SR5.
USE WITH CARE.
