Flow Chart 6: Flag Change Mode
RS = Rotary Switch Position
LED Colour
RS = 0
MechTool
TM
Mode - Entry
Set RS to position 0 Green
Press and hold program button for a
minimum of 2 seconds.
Red
Release the program button when the
LED flashes Yellow.
Flashing Yellow
RS = 6
Flag Change Mode
Set RS to position 6 Flashing Yellow
Press and release the program button. Yellow-Green
See Table 4
Set the rotary switch corresponding to
the flag number to be changed.
i.e. position 1 = flag 1,
position 9 = flag 9.
Press and release the program button. Flashing Yellow
RS = 0
MechTool
TM
Mode - Exit
Set RS to position 0 Flashing Yellow
Press and hold program button for a
minimum of 2 seconds.
Yellow-Green
Release the program button when the
LED = Yellow-Green.
Green
This programs the selected flag change to EEPROM.
Table 4: Eeprom flags v Rotary switch position
Rotary switch
position.
Flag function.
Rotary switch
position.
Flag function.
0 Teach off. 5 Diagnostic on.
1 Teach on. 6 Individual window tweaks disabled.
2 Alarm off. 7 Individual window tweaks enabled.
3 Alarm on. 8 Secure tuning disabled.
4 Diagnostic off. 9 Secure tuning enabled.
