5. Setting up the device
15
Menu level Parameterisation level
Display values for setpoints,
Under this parameter setpoints are defined according to their value. At the sensor
calibration, like at final value/offset, one is asked at the end if a calibration shall be
activated.
Analog values for setpoints,
The setpoints are always preset according to the selected input signal mA/V. The
demanded analog values can be freely adjusted in ascending order.
Device undercut,
Default:
With this function the device undercut ( ) can be defined on a definite
value. Exception is input type 4-20 mA, it already shows undercut at a signal
<1 mA, so a sensor failure is marked.
Display overflow,
Default:
With this function the display overflow ( ) can be defined on a definite value.
Back to menu group level,
With [P] the selection is confirmed and the device changes into menu group level
.
