14
5. Setting up the device
Menu level Parameterisation level
Rescaling the measuring input values, :
Default:
With this function, rescale the input value of e.g. 3.5 mA (works setting) without
applying a measuring signal.
Setting up the tare/offset value, :
Default:
The given value is added to the linearized value. In this way, the characteristic line
can be shifted by the selected amount.
Setting up the balance point,
Default:
The balance point for the final value can be chosen from the measuring range by
with 0…10 V or with 0…20 mA in %. The preset 80.000% result from
the widespread detuning of the melt pressure sensors.
Setting up the physical unit,
Default:
Choose between the above shown physical units. It will be displayed on the 5th
digit of the display, thus the range of value is limited to -1999…9999.
Number of additional setpoints,
Default:
30 additional setpoints can be defined to the initial value and final value, so linear
sensor values are not linearised. Only activated setpoint parameters are
displayed.
