2.7 Connect to Motor
The SS motors have two cables. One is the motor power cable, the other one is the encoder
feedback cable. Plug the motor power cable into the motor connector on the drive and plug the
encoder feedback cable into the encoder feed back connector on the drive.
Do not damage or drag the cables on the motor.
Motor Connector
Encoder Feedback Connector
MMAA++
MMBB


11
MMBB++
2
MMAA
33
4
1
3
5
7
9
11
13
15
2
4
6
8
10
12
14
16
A+
B+
Z+
+5V
U+
V+
W+
GND
A

B

Z

U

V

W

