SS03/05/10-S/Q/C Hardware Manual
400-820-9661
1 Introduction
Thank you for selecting the MOONS’ SS series Step-Servo drive and motor. SS series combines
servo technology with an stepper motor to create a product with exceptional feature an broad
capability.
1.1 Features
 Programmable, digital step-servo drive and motor package
 Operates from a 24 to 75 volt DC power supply
 Control modes:
Torque Control
* Analog input
* SCL command
Velocity Control
* Digital input Control Velocity
* Analog velocity
* SCL command Velocity
Position Control
* Digital Input
 Pulse & Direction
 CW/CCW Pulse
 A/B quadrature(Encoder following)
* Analog Control
* SCL command
Q programming(-Q or -C model)
* Stand alone operation
CANopen (-C model only)
 Compliant with CiA301 and CiA402
 RS-232 serial communication
 Optional RS-422/485 communication
 Encoder resolution: 20000 counts/rev for AM17/23/24/34SS motor
 4096 counts/rev for AM11SS motor
 SS03 output current: continuous 3A, boost 4.5A
 SS05 output current: continuous 5A, boost 7.5A
 SS10 output current: continuous 10A, boost 15A
 8 optically isolated digital inputs,5-24VDC
 4 optically isolated digital outputs,max30V/100mA
 DQDORJLQSXVFDQEHFRQ¿JXUHGWR999RU9VLJQDOUDQJHV
 Technological advance
Full servo control, Closed loop,
(I¿FLHQW$FFXUDWH)DVW6PRRWK
Intelligent, Compact
