Rev. 1.1

0004102014

SS03/05/10-S/Q/C Hardware Manual

400-820-9661

4 Mounting the Drive

Use the M3 or M4 screw to mount the SS series drive .The drive should be securely fastened to a

VPRRWKÀDWPHWDOVXUIDFHWKHZLOOKHOSFRQGXFWKHDWDZD\IURPWKHFKDVVLV,IWKLVLVQRWSRVVLEOH

IRUFHGDLUÀRZIURPDIDQPD\EHUHTXLUHGWRSUHYHQWWKHGULYHIURPRYHUKHDWLQJ

 1HYHUXVHWKHGULYHLQDSODFHZKHUHWKHUHLVQRDLUÀRZRUWKHVXUURXQGLQJDLULV

more than 40ć.

 Never put the drive where it can get wet or where metal or other electrically

conductive particle particles can get on the circuity.

 $OZD\VSURYLGHDLUÀRZDURXQGWKHGULYH:KHQPRXQWLQJPXOWLSOH66GULYHVQHDU

each other, maintain at least 1.5cm of space between drives.

5 LED Display

SS series have two 7-segments LED,which is used to display operation mode ,error code ,bus

address and communication baud rate.

LED1 is used to indicate operation mode and error code. When drive has no error ,LED1 is

VROLGRQWRLQGLFDWHRSHUDWLRQPRGH:KHQGULYHKDVHUURU/('ZLOOÀDVKDWDVHFRQGUDWHWR

indicate error code. The dot point of LED1 is to indicate whether the drive is enabled. When the

dot point is on ,the drive is enabled When the dot point is off,the drive is disabled.

5.1 Operation Mode

Ɣ

1:CM1(Commanded Torque Mode)

2:CM2(Analog Torque Mode)

3:CM11~14(Analog Velocity Mode)

4:CM15~18(Velocity Mode)

5:CM10(Commanded Torque Mode)

6:CM7(Digital Position Mode)

7:CM21(Point to Point Mode)

8:CM22(Analog Position Mode)
