SS03/05/10-S/Q/C Hardware Manual
Encoder Extension Cable for AM17/23/24/34SS motor
P/N
Length
Wiring Diagram
2104-100 1M
PIN὇J1Ὀ Colour(Signal) PIN὇J2Ὀ
2104-300 3M
A8 Blue὇A+Ὀ A8
2104-500 5M
B8 Blue/Black὇A-Ὀ B8
2104-1000 10M
A7 Green὇B+Ὀ A7
B7 Green/Black὇B-Ὀ B7
A6 Yellow὇Z+Ὀ A6
B6 Yellow/Black὇Z-Ὀ B6
A5 Red὇+5VὈ A5
B5 Black὇GNDὈ B5
A3 Brown὇U+Ὀ A3
B3 Brown/Black὇U-Ὀ B3
A2 Gray὇V+Ὀ A2
B2 Gray/Black὇V-Ὀ B2
A1 White὇W+Ὀ A1
B1 White/Black὇W-Ὀ B1
B4 Shield B4
Encoder Extension Cable for AM11SS motor
P/N
Length
Wiring Diagram
2108-100 1M
PIN὇J1Ὀ Colour(Signal) PIN὇J2Ὀ
2108-300 3M
10 Blue὇A+Ὀ A8
2108-500 5M
9 Blue/Black὇A-Ὀ B8
2108-1000 10M
8 Green὇B+Ὀ A7
7 Green/Black὇B-Ὀ B7
6 Yellow὇Z+Ὀ A6
5 Yellow/Black὇Z-Ὀ B6
3 Red὇+5VὈ A5
4 Black὇GNDὈ B5
Brown὇U+Ὀ A3
Brown/Black὇U-Ὀ B3
Gray὇V+Ὀ A2
Gray/Black὇V-Ὀ B2
1White὇W+Ὀ A1
2 White/Black὇W-Ὀ B1
12 Shield B4
L
Housing：J2DF-16V-KX-L(JST)
Crimp：SJ2F-002GF-P1.0(JST)
Housing：J21DPM-16V-KX(JST)
Crimp：SJ2M-002GF-M1.0N(JST)
1
8
1
8
1
8
1
8
J2
J1
AB
AB
Wire protect cover: J21PF-16SCA(JST)
Wire protect cover: J21PF-16SCB(JST)
Housing：501646-1200(Molex)
Crimp： 501648-1000(Molex)
Housing：
J21DF-16V-KX-L(JST)
Crimp： SJ2F-002GF-P1.0(JST)
B
1
A
1
88
1
11
2
12
J1
L
J2
