Moons' SS03-S-A User Manual

9
Rev. 1.1
0004102014
400-820-9661
SS03/05/10-S/Q/C Hardware Manual
The connectors and other points of interest are illustrated below:
Model
SS03-S-A SS05-S-A SS10-S-A
SS03-Q-A SS05-Q-A SS10-Q-A
Model
SS03-S-R SS05-S-R SS10-S-R
SS03-Q-R SS05-Q-R SS10-Q-R
SS03-C-C SS05-C-C SS10-C-C
Ground Screw
LED
RS-232 Connector
I/O Connector
Encoder Connector
Motor Connector
Power Connector
LED Display
RS-232 Connector
I/O Connector
Encoder Connector
Motor Connector
Power Connector
Ground Screws
Rotary Switch
DIP Switch
Daisy chain

Moons' SS03-S-A Specifications

General

Brand	Moons'
Model	SS03-S-A
Category	Servo Drives
Language	English
