20
Rev. 1.0
09/27/2023
400-820-9661
Multi-axis Series Hardware Manual
L/A OUT
ERR
L/A IN
RUN
X3
X4
X5
X7
X8
XCOM
Y1
Y3
YCOM
24V+
BRAKE
24V-
L/A OUT
ER
L/A IN
RU
SSDC06/10-4X-ECX SSDC06/10-2XU-ECX
SSDC06/10-4XU-ECX
I/O Connector Diagram
SSDC06/10-4X-ECX
SSDC06/10-4X-ECX-S
