43
Rev. 1.0
09/27/2023
Multi-axis Series Hardware Manual
400-820-9661
7.2.2 Extended motor cableFor SSDC drive and AM11RS motor
Housing:51065-0600(Molex)
Crimp:50212-8000(Molex)
Housing:
39-01-3048(Molex)
Crimp:39-00-0038(Molex)
2
1
4
3
6
1
J1
L
J2
Model
Length(L) Description
Wiring Diagram
2103-100 1M Standard type PIN(J1) Color (Signal) PIN(J2)
2103-300 3M Standard type 1 Blue(B-) 1
2103-500 5M Standard type 2 Red(B+) 2
2103-1000 10M Standard type 3 Green(A-) 3
2128-100-C05 1M Flexbile type 5 million times bends 4 Black(A+) 4
2128-300-C05 3M Flexbile type 5 million times bends
2128-500-C05 5M Flexbile type 5 million times bends
2128-1000-C05 10M Flexbile type 5 million times bends
7.2.3
Extended motor cableFor SSDC drive and AM17/23/24SS-NAM17/23/24RS motor
L
A
30±3
5±3
23.9
A
11.6
J1
4
3
2
1
25
B
70
5±3
19.6
11.6
2
1
4
3
14.4
B
J2
Housing:39-01-3049(Molex)
Crimp:39-00-0040(Molex)
Housing:39-01-3048(Molex)
Crimp:39-00-0038(Molex)
5.8±0.2
Model
Length(L) Description
Wiring Diagram
2027-0100
1M Standard type PIN(J1) Color (Signal) PIN(J2)
2027-0300
3M Standard type 1 Blue(B-) 1
2027-0500
5M Standard type 2 Red(B+) 2
2027-1000
10M Standard type 3 Green(A-) 3
2027-0100-C05
1M Flexbile type 5 million times bends 4 Black(A+) 4
2027-0300-C05
3M Flexbile type 5 million times bends
2027-0500-C05
5M Flexbile type 5 million times bends
2027-1000-C05
10M Flexbile type 5 million times bends
7.2.4
Extended motor cableFor SSDC drive and AM34SS-NAM34RS motor
L
A
30±3
5±3
23.9
A
11.6
J1
4
3
2
1
25
B
70
5±3
19.6
11.6
2
1
4
3
14.4
B
J2
Housing:39-01-3049(Molex)
Crimp:39-00-0040(Molex)
Housing:39-01-3048(Molex)
Crimp:39-00-0038(Molex)
5.8±0.2
Model
Length(L) Description
Wiring Diagram
2028-0100
1M Standard type PIN(J1) Color (Signal) PIN(J2)
2028-0300
3M Standard type 1 Blue(B-) 1
2028-0500
5M Standard type 2 Red(B+) 2
2028-1000
10M Standard type 3 Green(A-) 3
2028-0100-C05
1M Flexbile type 5 million times bends 4 Black(A+) 4
2028-0300-C05
3M Flexbile type 5 million times bends
2028-0500-C05
5M Flexbile type 5 million times bends
2028-1000-C05
10M Flexbile type 5 million times bends
