Moons' SSDC Multi-axis Series User Manual

26
Rev. 1.0
09/27/2023
400-820-9661
Multi-axis Series Hardware Manual
6 Reference Materials
6.1 Technical Specifications
Power Amplifier
Amplifier Type Dual H-Bridge
Current Control PWM
Output Current
（peak of sin）
SSDC06-2XU-ECX：Continuous Current 2x6A max，Boost Current 2x7.5A max (1.5s)；current limitation
auto set-up by attached motor
SSDC10-2XU-ECX：Continuous Current 2x10A max，Boost Current 2x15A max (1.5s)；current limitation
auto set-up by attached motor
SSDC06-2XU-ECX-S：Continuous Current 2x6A max，Boost Current 2x7.5A max (1.5s)；current limitation
auto set-up by attached motor
SSDC10-2XU-ECX-S：Continuous Current 2x10A max，Boost Current 2x15A max (1.5s)；current limitation
auto set-up by attached motor
SSDC06-4X-ECX：Continuous Current 4x6A max，Boost Current 4x7.5A max (1.5s)；current limitation auto
set-up by attached motor
SSDC10-4X-ECX：Continuous Current 4x10A max，Boost Current 4x15A max (1.5s)；current limitation auto
set-up by attached motor
SSDC06-4X-ECX-S：Continuous Current 4x6A max，Boost Current 4x7.5A max (1.5s)；current limitation
auto set-up by attached motor
SSDC10-4X-ECX-S：Continuous Current 4x10A max，Boost Current 4x15A max (1.5s)；current limitation
auto set-up by attached motor
SSDC06-4XU-ECX：Continuous Current 4x6A max，Boost Current 4x7.5A max (1.5s)；current limitation
auto set-up by attached motor
SSDC10-4XU-ECX：Continuous Current 4x10A max，Boost Current 4x15A max (1.5s)；current limitation
auto set-up by attached motor
SSDC06-4XU-ECX-S：Continuous Current 4x6A max，Boost Current 4x7.5A max (1.5s)；current limitation
auto set-up by attached motor
SSDC10-4XU-ECX-S：Continuous Current 4x10A max，Boost Current 4x15A max (1.5s)；current limitation
auto set-up by attached motor
Power Supply
SSDC06/10-2XU-ECX: 24 - 70 VDC
SSDC06/10-2XU-ECX-S: 24 - 70 VDC
SSDC06/10-4X-ECX: 24 - 70 VDC
SSDC06/10-4X-ECX-S: 24 - 70 VDC
SSDC06/10-4XU-ECX: 24 - 70 VDC
SSDC06/10-4XU-ECX-S: 24 - 70 VDC
Input Voltage
Range
SSDC06/10-2XU-ECX: 18-75 VDC
SSDC06/10-2XU-ECX-S: 18-75 VDC
SSDC06/10-4X-ECX: 18-75 VDC
SSDC06/10-4X-ECX-S: 18-75 VDC
SSDC06/10-4XU-ECX: 18-75 VDC
SSDC06/10-4XU-ECX-S: 18-75 VDC
Protection Over-voltage, under-voltage, over-temp, motor/winding shorts (phase-to-phase, phase-to-ground)
Controller
Micro-Step Level The software is adjustable and can be configured to any even number between 200-51200 steps/rev
Electronic
Gearing &
Encoder
Resolution
4096 counts/rev( for AM08/11/17/23/24/34RS motors)
20000 counts/rev( for AM17/23/24/34SS-N motors )
