Moons' SSDC Multi-axis Series User Manual

34
Rev. 1.0
09/27/2023
400-820-9661
Multi-axis Series Hardware Manual
AM24 Series
B1
B
A 1 FLAT
A
47.14
4 7.14
φ38.1
60
4-φ4.5
1.5
8
110
7 7.4
33
300
Model A A1 B B1 Connector On Cable
AM24RS3DMA
φ
10 9.5 24 20
Motor cable
Housing: 39-01-3048 (Molex)
，
1pcs
Crimp: 39-00-0038 (Molex)
，
4pcs
Encoder cable
Housing: 1-1827864-6 (Tyco)
，
1pcs
Crimp: 1827569-2 (Tyco)
，
11pcs
AM24RS3DMB
φ
8 7.5 20.6 15
AM24SS3DGA-N
φ
10 9.5 24 20
Motor cable
Housing: 39-01-3048 (Molex)
，
1pcs
Crimp: 39-00-0038 (Molex)
，
4pcs
Encoder cable
Housing: 1-1827864-0 (Tyco)
，
1pcs
Crimp: 1827569-2 (Tyco)
，
15pcs
AM24SS3DGB-N
φ
8 7.5 20.6 15
*Note: The motor outlet connector in the table refers to the connector of the motor outlet line, not the plug-in connector. For the
model of the plug-in connector, see related extension cable
