You may configure what is displayed (source) and Precision format (decimal places).
Source– Select your Source type Process Variable (PV), Analog Output Current/Voltage, or
Toggle PV and AO.
Precision– Select the number of decimal places/resolution of your display (default is Auto).
Note: Once you have congured all parameters, download to the unit by selecting “Download”
in the Transfer dropdown menu located in the Status Bar. Or, click the button in the Menu
Bar.
Figure 5.3. Display Tab
Display
