Section 10- Ordering Information
The STA TPRG ordering information is detailed below.
Accessories
Unit Input Output Power Options Housing
STA
Programmable
SIL 2 Compliant
Programmable
Safety Trip
Alarm
TPRG Programs to
accept:
RTD: 2-, 3- and
4-wire;
platinum, copper,
and nickel
Thermocouple:
J, K, E, T, R, S, N,
C, B
Ohms: 0-4000
ohms
(Potentiometer, 4000
ohms max.)
Millivolts: –50 to
+1000mV
U
Accepts
any power
input range
between
21.6-375Vdc
or
90-260Vac.
-AO Analog output
(isolated and
linearized)
scalable for any
range between
0-21.6mA into
1 kohms or
–0.2-10.5V into
2 kohms
(Current output is
user-selected for
internal, source or
external power, sink)
- EMP EMPHASIS
Version with keyed
terminals and lcoked
rmware version
DIN
DIN-style
housing mounts
on 35mm
(EN50022) Top
Hat DIN-rails
FLB Flange
bracket provides
a secure mount
for high vibration
applications
When ordering, specify: Unit / Input / Output / Power / Options [Housing]
Model number example: STA / TPRG / 3PRG / U / -AO [DIN]
3PRG Dual Process
Relays and One
Fault Relay
(Relays are
single-pole/
double-throw;
SPDT, 1 form C,
rated 3A@250Vac
or 3A@30Vdc,
50/60Hz, non-
inductive)
Process Relays #1
and #2
individually congure
for: High Alarm
Low Alarm
Normally Open
Normally Closed
(Both relays are
xed as Failsafe)
Fault Relay #3 is
xed as Failsafe
Part Number
700-702-32
Part Number
750-75E05-01
Part Number
803-053-26
Part Number
804-030-26
FMEDA Report consistent with IEC 61508-2:2010 providing
the information necessary to design a Safety Instrumented
System (One copy provided free with each order Upon
Request)
Intelligent PC Conguration Software One CD copy
provided free with each order (Standard) or, Line Item or Unit
(Upon Request)
Serial Conguration Cable for use in connecting the STA to
a PC via 9-Pin Serial port
Fuse Protected, Non-isolated USB Communication Cable
for use in connecting the STA to a PC via USB Port
Each STA order comes with one copy of our Intelligent PC Conguration Software. Use the chart
below to order additional parts.
Programmable RTD, T/C, Ohms, mV and Potentiometer Safety Trip Alarm
STA
TPRG
SECTION 10
