7. PROBE HOLDER
To install the pH probe, assemble the probe holder (see exploded view below) in the accessories holder, without
Teflon tape.
Assembled view
→ Nut to loosen/tighten the probe
Screw on and tighten by hand
Exploded view
8. SALT/TEMPERATURE/WATER SHORTAGE SENSOR
Screw on and tighten by hand the sensor into the accessories holder.
9. FLOW SENSOR
Insert into the accessories holder
