ENGINE CONTROLS
1� MD3 DISPLAY PANEL - Displays all machine information and functions.
2� IQAN DIAGNOSTICS PORT - USB connection for the MORBARK INTEGRATED CONTROL SYSTEM.
3� DATA LINK HOOKUP - Provides access for the CAT tech computer.
4� DATA LINK HOOKUP - Provides access for the John Deere or Cummins tech computer.
5� TETHER - Provides access for the remote tether.
6� KEYSWITCH - This key, when turned will start or stop the engine.
7� FEED FORWARD - Press toggle to start the feed wheels moving forward.
8� FEED REVERSE - Press toggle to start the feed wheels in reverse.
9� YOKE UP - Press toggle to raise the yoke into the up position.
10� YOKE DOWN - Press toggle to lower the yoke into the down position.
11� DEFLECT UP - Press toggle to direct the ow of chips up.
12� DEFLECT DOWN - Press toggle to direct the ow of chips down.
13� SPOUT LEFT - Press toggle to turn the spout to the left.
14� SPOUT RIGHT - Press toggle to turn the spout to the right.
15� SPOUT LOWER - Press toggle to lower the spout for transport or storage.
16� SPOUT RAISE - Press toggle to raise the spout for chipping.
17� CONTROL MODE - Press toggle to switch machine functions from the control panel to the radio (wireless) control or to
the tether control.
18� CLUTCH - This is an optional function. If your machine is equipped, press toggle and to engage the clutch. Pressing
again will disengage the clutch.
19� FAN PURGE - Press toggle to initiate the fan purge cycle. Once the cycle is initiated, the feedworks will stop and the
radiator fan will reverse direction. When the cycle is complete, the feedworks will start and the fan will return to normal
operation.
CAUTION: Use horn to clear the area before start up and to warn someone they are too close to the work area�
20� HORN - Press toggle to activate the horn.
21� THROTTLE INCREASE - Press toggle to increase engine RPM.
22� THROTTLE DECREASE - Press toggle to decrease engine RPM.
NOTE: THE BUTTON LAYOUT AND NUMBER OF BUTTONS WILL DIFFER� VERIFY WHAT YOUR MACHINES HAS
PRIOR TO USE�
