38
YOKE LOCK PROCEDURE
1� Throttle engine down to an idle and disengage the clutch. (If your machine has a mechanical clutch you will need to
manually disengage your clutch with the handle.)
DANGER/THROWN DEBRIS, CUT, PINCH HAZARD: Make sure the drum has come to a complete stop before at-
tempting any maintenance�
CAUTION: Do not use your hand to check for drum movement�
2� Push yoke lock in to end of slot and turn clockwise in slot.
DANGER/CRUSH HAZARD: Yoke lock must be used anytime the yoke is raised for maintenance�
DANGER/THROWN DEBRIS, CUT, PINCH HAZARD: Shut power unit off and follow lockout procedures before
any maintenance is performed�
SAFETY OPERATION
