REMOTE CONTROLS
1� LEFT TRACK FORWARD/REVERSE - Push toggle switch up to move the left track forward. Push toggle switch down to
move the left track in reverse.
2� THROTTLE INCREASE/DECREASE - Push toggle switch up to increase the engine throttle. Push toggle switch down
to decrease engine throttle.
3� ENGINE STOP - Push this button down to stop the engine (this should only be used in case of emergency). Twist button
to the right and release to reset (the engine will not restart without resetting the button).
4� FEED FORWARD/REVERSE - Push toggle switch up to start the feed wheels in the forward motion. Push toggle switch
down to reverse the feed wheels.
5� RIGHT TRACK FORWARD/REVERSE - Push toggle switch up to move the right track forward. Push toggle switch
down to move the right track in reverse.
6� DEFLECT UP/DOWN - Push toggle switch up to raise the spout deect. Push toggle switch down to lower the spout
deect.
7� SPOUT TURN LEFT/RIGHT - Push toggle switch up to turn the spout to the left. Push toggle switch down to turn the
spout to the right.
8� FEED SPEED - Turn knob to the right to increase the speed of the feed works. Turn knob to the left to decrease the
speed of the feed works.
9� YOKE UP/DOWN - Push toggle switch up to raise the yoke. Push toggle switch down to lower the yoke.
10� TRACK SPEED - Turn knob to the right to increase the speed of the tracks. Turn knob to the left to decrease the speed
of the tracks.
11� POWER - Press and hold switch to turn on the transmitter/remote. Press again and hold to turn the transmitter/remote
off.
12� STATUS LIGHT - GREEN means transmitter is on. RED means that the battery is low.
13� SPOUT RAISE/LOWER - Push toggle switch to raise the spout. Push toggle switch to lower the spout. (This is also
called SPOUT FOLD/UNFOLD).
14� FAN PURGE - Press toggle to initiate the fan purge cycle. Once the cycle is initiated, the feedworks will stop and the
radiator fan will reverse direction. When the cycle is complete, the feedworks will start and the fan will return to normal
operation.
