Gauge Battery Charge
Top Display:
11% to 25%
1
Top Display:
10% or less (The gauge begins blinking at 10%)
4.1.2
Accessing the Battery Info screen
This feature displays the current capacity and charges cycles of your battery when an IMPRES battery
is powering your radio. This feature must be enabled in your radio to see the information.
Procedure:
1
or to Batt.
2 Press the Menu Select button directly below Batt.
Your radio displays the following result:
Charge Percentage
Percentage of current battery capacity.
Remaining Capacity
Remaining power of the battery in mAh.
Estimated Charges
Number of charges cycles the battery has gone through.
3 To return to the Home screen, press the Menu Select button directly below Exit.
4.1.3
HAZLOC Battery Type Detection
This feature alerts you when there is a HAZLOC certification mismatch between the radio and the
battery. This feature supports IMPRES batteries only.
During power-up, the following scenarios occur if there is a mismatch:
• The radio continuously displays Wrong Battery with red intelligent backlight.
• The radio Voice Announcement announces the programmed Wrong Battery.
• The battery icon blinks continuously.
• A repetitive tone sounds.
MN001424A01-AW
Chapter 4 : Status Indicators
27
