See Programmable Features on page 22 for more information on the various programmable features
of your radio.
Procedure:
1 Perform one of the following actions:
• Press the preprogrammed Info button.
• or to Info and press the Menu Select button directly below Info.
2
or to Control map and press the Menu Select button directly below Sel.
The display shows the Control Map screen.
3 Perform one of the following actions:
•
or to scroll through the various information.
• Press the Menu Select button directly below Back to return to the previous screen.
• Press
to return to the Home screen.
7.28.18
Front Panel Programming
This feature only supports Model 3.5 and Model 2.5.
You are able to customize certain feature parameters in Front Panel Programming (FPP) to enhance
the use of your radio.
The radio can be programmed in two ways:
• Front Panel Programming (FPP) using the front panel controls of the radio.
• Customer Programming Software (CPS), with the radio connected to a PC computer.
There are two methods to program a channel within a zone. Either:
• Select the zone and channel through the radio interface, and then initiate the FPP feature. Or,
• Initiate the FPP feature, and then select the zone and channel.
NOTE: When any of the Rx parameters such as Rx frequency, Rx PL, Rx DPL, and Rx NAC
is changed, FPP automatically copies these Rx parameter values to the equivalent Direct
operation (also known as Talkaround operation) parameters. If you use FPP to change the Rx
frequency to be the same as the Tx frequency and subsequently use the CPS to read then
write to the radio, Direct/Talkaround mode will operate differently from when a receive channel
parameter value is changed through FPP. Refer to the CPS help files for a description of Direct/
Talkaround Mode operation, in respect to a CPS write to the radio.
7.28.18.1
Initiating the FPP Feature
Prerequisites: Before using this feature, you should:
• Familiarize yourself with the your radio.
• Remove the universal connector seal or any other accessories if it is attached to the radio.
Procedure:
1 Press
or to FPP.
2 Press the Menu Select button directly below FPP.
MN001424A01-AW
Chapter 7 : Advanced Features
124
