Chapter 4
Test Setup and Testing
WARNING: Any Level 3 repairs can deeply affect the performance of the MXM600 with Enhanced
Control Head terminal and may cause a new tuning procedure.
This tuning procedure can only be applied by certain authorized Motorola Solutions depots where the
appropriate TEST&TUNE EQUIPMENT is available.
The appropriate TEST&TUNE EQUIPMENT is a special automated test equipment that is only available
at selected Motorola Solutions factories and Motorola Solutions repair centers.
NOTE: This chapter provides a general overview for testing Motorola Solutions radios.
There may be some differences caused by the variety of software versions running on the testing
equipment. Please consult the user guides of the respective testing equipment for further details.
4.1
Typical Test Setup
Perform the following instructions before testing:
● Connect the DC cable to the DC connector on the terminal.
● Connect the other side of the DC cable to the DC output connector on the power supply.
● Connect an RF cable to the N-type RF Connector of the IFR.
● Connect the other side of the RF cable to the antenna connector on the terminal.
● Set the DC voltage on the power supply to 13.2 Volts.
● Switch on the terminal.
MN009999A01-AA
Chapter 4: Test Setup and Testing
40
