● Vector RMS (Spectrum Analyzer)
● Frequency Error (Vector Analyzer)
7. Perform one of the following actions:
Options Actions
Power Analyzer Graph
a. Press power ana.
b. Check that the power frame falls within the limits.
Spectrum Analyzer Diagram
a. Press spec ana.
b. Monitor the transmitter frequency.
Vector Analyzer Diagram
a. Press vector ana.
b. To monitor constellation diagram, perform one of the fol-
lowing actions:
● Press vector error for vector error.
● Press mag error for magnitude error.
● Press phase error for phase error.
Vector Diagram
a. Press vector diagram.
b. To view the diagram, perform one of the following actions:
● Press symbol constel for graphical symbol constella-
tion.
● Press rotated vector to zoom in on the constellation.
● Press phase traject to view the trajectory of the con-
stellation.
8. Press End.
4.6
Manual Mode Testing
This section list the procedures for manual mode testing.
4.6.1
Preparation for Testing
Prerequisites: Verify that your radio is turned off.
Procedure:
1. Press 1,2, and 3 until the display turns on.
2. Press On/Off, or the Rotary Push Button to turn on your radio.
The display shows:
User test mode, Press any key to start, Press Soft Keys to scroll.
