Motorola solutions MXM600 - Table 35: Test Setup for 410-470 Mhz

No. Test Name Test Setup Terminal Set-
up
Test Condi-
tions
Limits
Max 5% Re-
sidual
5. Call Process-
ing Talk Back
1 kHz Test
Signal
Group Mode
Range 1
Test Group 1
-90 dBm
6. Call Process-
ing Call to Mo-
bile
Private Mode
Private Call
Private Mode
RF Gen Level
Burst Power
-90 dBm 35–40 dBm
Timing Error <= 0.25 Sym-
bols
Frequency Er-
ror
-/+ 100 Hz
Vector Error Max 10%
RMS,
Max 30%
Peak,
Max 5% Re-
sidual
7. Digital Duplex
Test (Tx)
RF Gen Level Private Mode -50 dBm
Burst Power 10–22 dBm
Timing Error <= 0.25 Sym-
bols
Frequency
Error
-/+ 100 Hz
Vector Error Max 10%
RMS,
Max 30%
Peak,
Max 5% Re-
sidual
The following table summarizes the required test setup for 410–470 MHz.
Table 35: Test Setup for 410–470 MHz
No. Test Name Test Setup Terminal Set-
up
Test Condi-
tions
Limits
1. IFR System
Setup and
Manual Test
Screen
Control Chan-
nel
2509
Traffic Chan-
nel
2509
Time Slot 3
Country Code 234
MN009999A01-AA
Chapter 4: Test Setup and Testing
45
