Figure 11: DREH Connector
1 2
3
4
Table 41: DREH Flex Connectors
Number Description
1 Gold pad contacts facing up
2 'THIS SIDE UP' facing up
3 18 pos Interface Flex
4 40 pos Main Flex
MN009999A01-AA
