Motorola solutions MXM600 - Table 34: Test Setup for 380-430 Mhz

No. Test Name Test Setup Terminal Set-
up
Test Condi-
tions
Limits
Max 5% Re-
sidual
The following table summarizes the required test setup for 380–430 MHz.
Table 34: Test Setup for 380–430 MHz
No. Test Name Test Setup Terminal Set-
up
Test Condi-
tions
Limits
1. IFR System
Setup and
Manual Test
Screen
Control Chan-
nel
3605
Traffic Chan-
nel
3605
Time Slot 3
Country Code 234
Network Code 2392
Base Color 1
Location Area 224
Min Rx Level -110 dBm
Max Tx Level 40 dBm (10
W)
Access
Parameter
-33 dBm
Mobile Power 40 dBm (10
W)
Burst Type Normal
2. Base Station
Registration
RF Gen Level 390.125 MHz -90 dBm
3. Receiver
RSSI
RF Gen Level Cells Info
RSSI
TRACE
-90 dBm
4. Transmitter
Tests
RF Gen Level Range 1
Test Group 1
-90 dBm
Burst Power 35–40 dBm
Timing Error <= 0.25 Sym-
bols
Frequency
Error
-/+ 100 Hz
Vector Error Max 10%
RMS,
Max 30%
Peak,
MN009999A01-AA
Chapter 4: Test Setup and Testing
44
